Tag Archives: concrete polishing

Roadware 10 Minute Concrete Mender™ Top Applications

Roadware 10 Minute Concrete Mender™ top applications:

General full depth crack repair:

Use the high-penetration abilities of Roadware 10 Minute Concrete Mender™ to make full depth crack repair.



CRACK REPAIR

1. Clean out with diamond grinder and remove dirt and dust.
2. Flood with Roadware 10 Minute Concrete Mender™
3. Add a fine graded silica sand and additional liquid to grade.
4. Strike off excess material and allow to cure for 10 minutes at 70°F.
5. Open to traffic. Finish and blend with a grinding stone if desired.



SPALL REPAIR

1. Clean out with diamond grinder and remove dirt and dust.
2. Flood with Roadware 10 Minute Concrete Mender™
3. Add a fine graded silica sand and additional liquid. Work in one inch lifts to grade.
4. Strike off excess material and allow to cure for 10 minutes at 70°F.
5. Open to traffic. Finish and blend with a grinding stone if desired.

HAIRLINE CRACKS

1. Score the top of the crack with diamond blade or wire brush.
2. Remove dust with a vaccume.
3. Flood with Roadware 10 Minute Concrete
Mender™ supplied in twin cartridges and optional needle tip mixer.
4. Add a fine graded silica sand to larger areas and allow to soak in.
5. Strike off excess material and allow to
cure for 10 minutes at 70° F.
6. Open to traffic. Finish and blend with a
grinding stone if desired.

SPALLED CONTROL JOINT

(Fully cured non-moving)
1. Clean out with diamond grinder and remove dirt and dust. Score back spall with blade for a finished look.
2. Flood with Roadware 10 Minute Concrete Mender™
3. Add a fine graded silica sand and additional liquid to grade.
4. Strike off excess material and allow to cure for 10 minutes at 70°F.
5. Open to traffic. Finish and blend with a grinding stone if desired.

DELAMINATED SLAB

1. Drill hole into void.
2. Remove dust with a vacuum.
3. Flood with Roadware 10 Minute Concrete
Mender™ supplied in twin cartridges.
4. Add a fine graded silica sand and
additional liquid to fill holes to grade.
5. Strike off excess material and allow to
cure for 10 minutes at 70° F.
6. Open to traffic. Finish and blend with a
grinding stone if desired.

THRESHOLDS AND
UNEVEN SLABS

1. Clean out with diamond or wire grinder and remove dirt and dust. Score lower edge with diamond blade for a finished look.
2. Flood with Roadware 10 Minute Concrete Mender™
3. Add a fine graded silica sand and additional liquid to a mortar consistency.
4. Shape with a clean steel trowel and allow to cure for 10 minutes at 70° F.
5. Open to traffic. Finish and blend with a grinding stone if desired. Maintain existing expansion joint if necessary.

Cracked floor in data center repaired with Roadware 10 Minute Concrete Mender™.

When permanent repairs are needed for a data center that will operate 24/7/365, the contractor turns to Roadware 10 Minute Concrete Mender™. Concrete Mender’s Microdowling™ action penetrates deep into concrete cracks and can re-bond slabs back together to form a structural repair. The repairs can be polished flush in about 15 minutes leaving a smooth high performing surface.
Cracked concrete in a space to be converted to a data center in Omaha, Nebraska.
The cracked topping span at this data center needs to be repaired so a dust free environment can be maintained.
Roadware 10 Minute Concrete Mender™ is used to repair the cracks and spalls prior to concrete polishing.

Roadware 10 Minute Concrete Mender™is mixed with sand and applied with a margin trowel.  Unlike polyureas, Concrete Mender™ will not gum-up and will remain trowel-able for several minutes before setting.

Concrete crack repairs with Roadware 10 Minute Concrete Mender™ can be most any length, width or depth.

After about 10 minutes, repairs can be polished smooth using standard concrete polishing equipment. Concrete Mender™ will not smear into the surrounding surface under  the heat if the diamond polishing.

The polished floor is now smooth, dust free and ready for the data center.



The polished floor is now smooth, dust free and ready for the data center.



All about Roadware 10 Minute Concrete Mender™

At Roadware, we see lots of two-component polymer concrete repair products that claim to be just like Concrete Mender™. One even calls it self, “Quick Mender.”  They are all basically polyurea based products that are too thick to effectively penetrate concrete surfaces and are so reactive, they become too sticky and gooey to trowel in just a minute or two after mixing.  When you dig a little deeper, you will see a very distinct difference in genuine Roadware 10 Minute Concrete Mender™.

  • What is Concrete Mender? Proprietary Polyurethane Blend
  • Formulation: Classified
  • Manufacturing: South Saint Paul, Minnesota, USA
  • Origin: NATO program for rapid bomb damage repair on runways.
  • Function: To penetrate deep into concrete cracks, joints, and spalls creating a structural repair in 10 minutes.
  • Military Use: Classified
  • Civilian Use: Repair cracks, joints and spalls in commercial, industrial and civil applications.
  • Service Life: Indefinite
  • Cure Time: 10 Minutes at 70°F (21°C)
  • Distribution: Worldwide Distributor Network

Surface Tension:

Surface Tension is a measurement of the ability of a liquid to overcome its own internal friction and penetrate into a material like concrete. Roadware 10 Minute Concrete Mender™ has a surface tension One third of water. It will penetrate concrete cracks and fissures quicker and deeper than water. This low surface tension lets Concrete Mender™ penetrate normal bond lines and allows structural bonding with the aggregate in the concrete. See the electron microscope slide below.



Low surface tension has another little hidden benefit.  It allows Roadware 10 Minute Concrete Mender™ to be combined with more than two parts sand and still be workable and trowel-able.  Try that with a polyurea and you will have a gooey mess on your hands.




Roadware Microdoweling™ Technology:
Slab to slab micro-doweling action, provided by Roadware 10 Minute Concrete Mender, links concrete slabs together, locks them in place and allows for full-traffic, dynamic-load transfer, in 10 minutes. This micro-doweling action is more compatible with concrete and less re-active in harsh environments than even Poly-coated re-bar. Millions of micro-dowels penetrate, then bridge and bond, side by side, broken and jointed slabs. Hairline cracks, trench wide cracks, irregular cracks, cured control joints and variable depth spalls are candidates for this amazing technology.
In 10 minutes, at 70°F (21°C) , this micro-doweled bond has the same compressive and shear strength as poured and fully cured concrete. This makes bond-line failures a thing of the past. Parallel re-cracking, often experienced when epoxies cure out, are eliminated with Roadware’s micro-doweling technology.

Structural Polyurethane

Roadware 10 Minute Concrete Mender™ is a polyurethane based material that restores structural integrity and aggregate interlock to distressed concrete by using low surface tension and low viscosity to penetrate concrete surfaces and cross -linking polymer chains to bond directly to the concrete-aggregate matrix.  This bonding action utilizes capillary forces to self-inject polymer chains into the surrounding concrete. This material should have a modulus of elasticity less then the surrounding concrete and should not become brittle over time. This material may be combined with manufactured sand to form a PCC compatible polymer concrete that can structurally repair concrete cracks  and spalls.

Advantages– Due to the very low surface tension of the material and low viscosity, complete saturation bonding of cracks can be easily achieved. Minimal prep to remove lose debris is all that is normally required.  This can be considered a structural repair if the material is allowed to gravity flow to the full depth of the crack. Manufactured sand or quartz may be introduced into the repair as necessary to prevent under slab ponding and martial waste. For repair greater than 0.125 inches, specified sand may be added at a ratio of two parts sand to one part mixed polyurethane as the crack is filled to extend the material and add strength. The sand also brings the thermal coefficient of expansion of the repair material closer in-line with surrounding concrete. Polyurethanes of this nature may be applied in a wide range to substreight temperatures making them useful in frozen and cold storage warehouse applications or cold weather application below -20F (-23C). Repairs are typically ready to accept traffic in approximately 10 minutes at 72F (22C).

Toughness:

Roadware 10 Minute Concrete Mender™ mixed with sand gets about as hard as concrete, yet it’s modulus of elasticity is slightly less than concrete so it will move with the slab, not work against it.

Common uses for 10 Minute Concrete Mender™

Spalled control joints and cracks.
Spalls and holes.
Delamination Repair



Uneven slabs and thresholds.
Crack Injection using gravity:
Typical crack injection repair techniques involve epoxy, ports, pumps, and pressure to force thick epoxies into a crack.  Roadware 10 Minute Concrete Mender™ with its low surface tension can do same job in less time, less mess, and better performance.

Polishable:

Polishing your floor to a mirror like finish? Repairs made with Roadware 10 Minute Concrete Mender™ will not smear into the surrounding surface or gum-up diamond polishing pads.  You can even add natural sand to match the grain and color of the surrounding concrete.

The repair pictured above shows  Roadware Concrete Mender™ Off-white blended with plain concrete sand and a small amount of portland cement. This water-thin polyurethane is almost translucent. When we add nearly any type of dry sand or aggregate, we get a fast-curing polishable repair that blends beautifully with the surrounding concrete. Since this material is almost translucent, it resists shadowing effects due to over-banding when applied.

Lower Cost:

By adding two parts silica or quartz sand to a gallon of Concrete Mender™ you will yield about 2.2 gallons of repair material.

A gallon of polyurea or epoxy will yield a gallon of repair material.  That makes polyurea more expensive to use even at half the material cost! This does not even factor in the hidden costs of short repair life, damage to the surrounding concrete caused by pre-mature failure, or the cost of redoing the the repairs when they fail.



Packaging:

Roadware 10 Minute Concrete Mender™ hand packed with state-of-the-art packaging materials.  They have to be good. The very low viscosity and surface tension require it.

Bulk Application:
Due to the the extended working time formula, bulk mixing of Concrete Mender™ is easy.  Unlike polyureas that start to gel up instantly, Concrete Mender will remain workable and flowable for several minutes before curing begins.  Much less wasted product setting up in buckets.
Pin-point Application:
With a Roadware needle tip mixer, you can apply Concrete Mender™ within-point accuracy delivering product to where it is needed most. Our needles come as small as 1.2mm in diameter.  If you can get a finger nail in the crack, we can get some Concrete Mender in there as well.

Freezers:

Working in the cold?  We’re from Minnesota. We know first hand what it takes to work in freezing temperatures. Roadware 10 Minute Concrete Mender™ can be applied at temperatures below -30 F ( -34C).  That is really cold.  Exposed flesh will freeze in seconds.  That is almost too cold to go ice fishing. Most repair products would freeze solid before curing and quickly fail.  Roadware 10 Minute Concrete Mender™ generates its own heat. Curing will take several hours, but you will still get the same great performance.





Colors:
Roadware Concrete Mender™ comes in two standard colors.  Concrete Grey and natural off-white. Since a typical repair is made up of two parts sand to one part liquid, the color of the sand will determine the color of the finished repair.  By adding colored quartz sand to off-white Concrete Mender, you can make custom colors as needed.
Specialty Applications:
We also custom make Concrete Mender in Safety Yellow, Red, Blue, and Black.  Use Concrete Mender Yellow to create permanent safety lines and marks in difficult areas like cooler and freezer floors.
Safety:
Roadware 10 Minute Concrete Mender™ is completely self-reacting and does not out-gas solvents or VOC’s when curing.  This material meets FSIS guidelines for work is federally inspected meat and poultry plants.

History:

For over twenty years, Roadware 10 Minute Concrete Mender™ has performed without fail in thousands of applications. Many times outliving the facility itself.

Concrete Mender repair in a cold storage warehouse after 15 years of heavy forklift traffic.

Utilizing technology developed to repair bomb damaged runways for NATO, Roadware 10 Minute Concrete Mender™ was reformulated and brought to commercial markets in the early 1990’s.  You can find us in nearly every industry that has concrete floors, decks, slabs or surfaces.

Links:
Roadware 10 Minute Concrete Mender™

Availability:

Roadware 10 Minute Concrete Mender is made in the USA and is available from Roadware authorized distributors and dealers worldwide. Call 1-800-522-7623 or 1-651-457-6122 to find a dealer near you.

Specifications:

For complete specifications, ASTM testing data, and usage guidelines, please visit the Roadware Website.

Repair polished concrete with Concrete Mender™

Stop repairing polished concrete with polyurea joint fillers. They look like plastic, do not bond well, and do not hold-up over time. Concrete polishing lets the natural beauty of stones, sand, and rock shine through.  Your repair product should as well.

cbec1b48d1534cf9a2862736e4d80d23

We took the proven Microdoweling™ properties of Roadware 10 Minute Concrete Mender™ and combined it with natural sands, aggregates and pigments to make repairs that not only look great, but perform better than epoxies and polyureas.

polished-repair450

The repair pictured above shows  Roadware Concrete Mender™ Off-white blended with plain concrete sand and a small amount of portland cement. This water-thin polyurethane is almost translucent. When we add nearly any type of dry sand or aggregate, we get a fast-curing polishable repair that blends beautifully with the surrounding concrete. Since this material is almost translucent, it resists shadowing effects due to over-banding when applied.

Extreme Concrete Repair and Polish

How do polish a floor when your concrete is like this?

Deep cracks and surface spalling can make polishing jobs costly and difficult.  A lot of the top surface has to be removed to get to a smooth finish.

Roadware 10 Minute Concrete Mender™ is a great choice for filling out all the cracks, spalls and holes before polishing.

This floor was repaired by troweling down a thin layer of Concrete Mender and sand, then ground smooth. A liquid hardener completed the restoration and the floor was polished.



The floor shows zero failure shown here 3 years later in 2007.  The floor continues to perform today.



New Concrete Mender™ Mini Cartridge for precise application.

For the first time, Roadware 10 Minute C5150-mender-verticaloncrete Mender™, the industry’s only Microdoweling™ concrete repair polyurethane, is available in 50ml mini cartridges. The mini cartridge offers precise application control that is perfect for repairing hairline cracks. Each mini cartridge comes with a needle tip mixer and is simple to use. Use the 50 ml cartridge with the Roadware 5150 application tool. Each cartridge will repair about 10 feet of hairline cracks or 3 feet of 1/4 x 1/4 inch cracks.



Roadware 80105 50ml 10 Minute Concrete Mender™ mini cartridge with mixer and needle tip.





Polishing un-polishable Concrete

Polishing and honing concrete to smooth shiny surface is a great way to give an old warehouse floor new life. Sometimes, warehouse floors are too damaged and worn to make polishing practical. Floors that are full of cracks and spalls will require a large amount of grinding and polishing to achieve an acceptable surface. Roadware 10 Minute Concrete Mender™ may be used to restore the concrete surface and reduce the time and expense of heavy grinding. The Microdweling™ action of Roadware 10 Minute Concrete Mender™ can penetrate the surface of the cracks and spalls, fill in all the low spots, and make the floor ready for polishing.

Click on photos for a larger image.

Pitted, spalled and cracked surfaces may be unpractical to polish.



The first step is a light surface grinding to open up the cracks and remove any loose materials.

An initial grinding with metal resin pads reveals cracks and spalls.

Roadware 10 Minute Concrete Mender™ and fine silica sand mixed in bulk is troweled into the surface over the entire area and allowed to set.

Workers trowel Concrete Mender into place.

In about 10 – 30 minutes, the surface is polished using standard techniques. Roadware 10 Minute Concrete Mender™ will not gum-up polishing pads or smear into the surrounding concrete.

Surface polish using standard techniques.

After grinding, all pitting, cracks and spalls are filled and a smooth surface is quickly restored.

Concrete Mender repairs hold up perfectly during the polishing process.

After polishing, hardening and sealing, a beautiful polished floor is revealed.

Concrete Mender restored floor after polishing, hardening, and sealing.

Click here to learn more about polishing with Roadware 10 Minute Concrete Mender™

Special thank you to International Roadware Distributor Join K&C in Seoul, Korea for submitting this project.

Making Cracks Disappear

One question we get asked all the time is if we can make a crack disappear.  For the most part the answer has always been no. We can make a good repair and finish it as close as we can to the original color and surface texture. That was before Roadware MatchCrete™ Clear came along.  The photos below were sent in by a concrete polishing contractor. By using MatchCrete™ clear and sand that matches the surrounding concrete, the polished repair blends in very nicely with the concrete slab. When the floor is in service, you will have to look very carefully to find the repairs.  Try some Roadware MatchCrete™ Clear on your next polishing job. With a little technique and experimentation, you can get results like this.

dalton.008
Polished concrete repair with Concrete Mender™ Off-white.
Polished concrete repair with Concrete Mender™ Off-white.
 Did the crack disappear? If you don’t notice it anymore, what’s the difference?

Roadware compared to look-alikes.

Recently a customer sent me several cut sheets from other manufactures of look-alike concrete repair products and asked me to compare them with Roadware 10 Minute Concrete Mender™.  Here is how it played out.

Dear Dave,

We here at Roadware are familiar with the knock-off and look-alike products you submitted for our review. These products fall into the category of a low viscosity polyurea. Basically, what they have done is modify a standard polyurea joint filler and added a solvent to make it appear as a high-penetration Concrete Mender™-like product. They are all missing the key property and process that makes Roadware 10 Minute Concrete Mender™ unique and superior in overall performance. This process is called Microdoweling™.

Roadware’s Microdoweling™ process uses a proprietary formula of polyurethanes and additives to achieve a measured surface tension of 0.026 N/m. (1/3 of water) Surface tension is a measurement of a liquids ability to break free of its own molecular friction and flow into something else. Microdoweling™ is why Roadware 10 Minute Concrete Mender™ can penetrate easily into a concrete surface under adverse conditions, as is the case in distressed, broken and cracked concrete.
Other advantages for Roadware 10 Minute Concrete Mender™ are:

  • The lowest viscosity for easier mixing and blending.
  • Easy, one-step polishing and grinding. This material will not melt, smear, or gum up diamond polishing pads. An excellent parging compound.
  • Experienced and advanced packaging. Roadware cartridge packaging is reliable and works well in the field.
  • End-user color blending. New MatchCrete™ Concrete Mender can easily be manipulated into many colors by modifying the sand or adding pigments.
  • A modulus of elasticity that is slightly less then the concrete so repairs will move with the concrete and not against it.
  • Needle tip application. A complete system of needle-tip cartridge mixers for pin-point application and hairline crack repair.
It’s all in the data. Roadware backs up the Microdoweling™ process with independent testing data and publishes it on our website, www.roadware.us.
Thank you for continued support and please call us any time if you have any questions.
Best regards,


Kelton Glewwe
Vice President of Operations



Concrete Polishing: Crack, Joint and Spall Repair Are Critical To Lasting, Quality Jobs



By: Joe Noble

The days of super-sized everything arrived about a decade ago, making large concrete-floored buildings common in a sea of commercial applications, including box-retailing, airports, malls, convention halls, and more. It also created demand for concrete polishing unlike anytime in the past. Today, professionally polished or decorated concrete floors are coveted for their clean, low maintenance finish, their dust-free, smooth feel, and for their aesthetically pleasing look. Managers report how polished floors boost morale among employees, improve light reflectivity (reducing light usage) and garner positive customer comments.


The market for concrete polishing and design continues to flourish and evolve. What hasn’t changed is the need to repair cracks, chips, joints and spalls in the floor prior to polishing. Without the proper repair material, the repair will fail, sometimes quickly costing time and money.

Curtis Venable is president of C&C Construction Co., a concrete repair and polishing services provider. Venable said that cracks, spalls and other deformities in the concrete must be properly repaired before polishing. Use of an inadequate repair product, or improper use of a repair product can cause more problems than they solve.
“I don’t want to get a call from a client at midnight wondering why a chip repair popped out in the middle of his floor,” said Venable. “Improper or poor repair prior to polishing is bad service and undermines my credibility with my clients.”
While Venable utilizes various repair products depending on the job, he often relies on 10-Minute Concrete Mender™ by Roadware, Inc (www.concretemender.com). Concrete Mender combines with sand to form a tough instant polymer concrete.


Reliability
Venable uses Concrete Mender for several reasons. First, he said, Concrete Mender penetrates deep into concrete to establish a permanent bond with the host concrete, producing repairs that absorb the shock and transfers the load of heavy traffic without cracking or disbonding. Its chemical resistance means it can be applied in a wide range of temperatures.

“I know that it won’t melt, smear or come out of a repair when my polishing machines are run over it,” he said. “And I can apply it in cold temps found in freezers.”
Concrete Mender accomplishes its unbreakable bond through a process called Microdowling™. Microdowling drives the repair deep into the micro-fissures of the crack, joint or spall, where it forms an unbreakable bond with the existing concrete.

“The Microdowling capabilities eliminate the anxiety caused by the liability that I and all contractors must carry for each job,” he said. “I know of jobs that are going on six and seven years without Concrete Mender failing in any way.”


Application Efficiency
Besides performing for years, it cures in only 10 minutes. At a recent job in which Venable repaired and then polished an 110,000-square-foot concrete floor for a national grocery retailer, he used Concrete Mender for efficiency reasons.
Venable inspected every chip, crack and spall before the job began, looking for joints where the filler has come out, anchor bolt holes, corner chips and spalls. He assessed each repair, and then made recommendations that clients repair each one.

“I put six people on polishing machines to work at the site for almost three weeks,” he recounted. “It becomes expensive if I have to wait for the repair material to set. Concrete Mender takes only 10 minutes.”


Blending
Finally, Venable said his customers require that the shade of the repair material match the existing concrete for aesthetic reasons. Large retailers, such as Home Depot and Sam’s Club, understand that today women are making many of the purchasing decisions for the home, including home repair. Because women prefer shopping in light and well-kept stores, shiny, clean floors are important to a retailer’s image. A patchwork of different repair shades and colors has become unacceptable among peer retailers.

After hardening, Concrete Mender blends flawlessly with surrounding concrete, resulting in a near perfect color match. After polishing or coloring, a repair made with Concrete Mender is indistinguishable from the original floor.
“Having various shades and colors of repairs on the floor is unacceptable in the concrete polishing industry,” said Venable. “Today, to meet the expectation of women shoppers, repairs must blend to give the appearance of a single, neat and clean finish.”

Concrete Mender can serve many demands in the concrete polishing industry. It hardens within 10 minutes, after which it can be treated like the surrounding concrete. It can be cut and polished, and won’t smear or come out in the process. It’s efficient for use on large jobs, including where heavy machinery is operated, airport hangers, freezers, retailers and more.
“Concrete polishing is an expanding market and becoming more competitive,” said Venable. “I have confidence in Concrete Mender to help me meet customer expectations of looks, performance and efficiency.”
For more information 10-Minute Concrete Mender, contact Roadware, Inc. at www.concremender.com.  For more information about C&C Construction, visit www.candcconst.com.

Contact Information:
Richard E. King 800-522-7623 or 651-457-6122
Kelton E Glewwe 800-522-7623 or 651-457-6122
Roadware Incorporated
381 Bridgepoint Way
South Saint Paul, MN 55075

Microdoweling™, Roadware 10 Minute Concrete Mender™, and respective logos are trademarks of Roadware, Inc. Copyright 2008.
